Solars and Tracking Gearboxes
Solar Tracking
Cone Drive has a long history of developing custom solutions for both single-axis and dual-axis solar tracker drives. As a global solar drive manufacturer we have the experience and the reach to deliver highly effective solar solutions.
Satellite Communication Positioning
The rapid expansion of the Ka-band technology has driven the need for precision motion control tracking capabilities for Satellite + Antennae positioning systems. Our custom solutions address azimuth + elevation motion control capable of meeting the tightest specifications.
Key Features
- Gated Product Development Process
- Specification Development
- 3D & 2D Design
- Simulation, FEA
- Engineering Analysis, DFMEA
- Prototyping
- Custom Solar Tracker Test Design & Design Verification
- Custom Solar Drive Manufacturing
TRACKING & POSITIONING GEARBOX SPECIFICATIONS
.
PRODUCT DEVELOPMENT
The Cone Drive Product Development Laboratory is a state-of-the-art facility directly adjacent to our Traverse City, Michigan manufacturing location. The lab has the capacity to test a wide range of gear reducer products, for both Cone Drive products as well as those manufactured by other companies. The lab includes capability to run a wide variety of tests including load testing for evaluating reducer performance and operating efficiency.
TEST + CONTROL
- Six product testing stands
- Servo cyclic control
- Simulated inertial loading
- Constant torque/load
- Durability/validation
- Accelerated life test
- Lubricant evaluation
- Static loading & stiffness
PRODUCT MEASUREMENT
- Displacement & motion
- Torque
- Thermal
- Efficiency
- Vibration
- Basic noise
- Transmission accuracy
